| Size Range 2″~160″（DN50~DN4000）
| Body Materials TI2 / TA2 Optional titanium grades: Gr.2 / Gr.7 / Gr.12 ASTM B381 F2 / TA2
|
| Temperature Range -320°F to 842°F（-196°C to 450°C）
| Stem Materials TI2 / TA2 Optional titanium grades: Gr.2 / Gr.7 / Gr.12 ASTM B381 F2 / TA2
|
| Maximum Allowable Operating Pressure ASME 150LB, 300LB, 600LB 900LB/ EN 1092 PN 10, 16, 25, 40, 63, 100, 150
| Seat Materials Features laminated stainless steel with graphite, hard-faced alloys, or soft seals (PTFE, RPTFE, Viton, EPDM) depending on application.
|
| Shut off Rating Zero Leakage
| Disc Materials TI2 / TA2 Optional titanium grades: Gr.2 / Gr.7 / Gr.12 ASTM B381 F2 / TA2
|
| Design Standard API 609, ASME B16.34, ASME VIII, API 600
| Flange Drilling ASME B16.5, ASME B16.47, EN 1092, ISO 7005
|
| End Connections Wafer, Lug, Double Flanged
| Testing standard ISO 5208, EN12266-1, API 6D, API 598, BS 6755
|
| Ports Full bore
| Connect Platform ISO5211, Bracket
|
| Face To Face AAPI 609, ASME B16.10, ISO 5752, EN 558
| Applications Oil and gas, steam, power generation, refining, chemical processing |
