CARTER VALVE PRODUCTS

Modulating Control Valves

Modulating control valves continuously adjust opening to keep a process variable stable under changing load. We supply control valve solutions for accurate flow/pressure/temperature regulation, with trim and sealing options matched to different media and operating ranges. Key features focus on controllability, repeatable positioning, and stable performance during frequent modulation. This helps you reduce process fluctuation, shorten tuning time, and improve product quality and energy efficiency in real plant conditions.

3-Way Mixing & Diverting Control Valve

3-Way Mixing & Diverting Control Valve

CVC-300M

• Size Range: 1/2″ – 6″ (DN 15 – DN 150)

• Pressure Rating: PN 16 / 25 / 40 (Class 150 / 300)

• Temperature Range: –60°C to +450°C (–76°F to 842°F), depending on material

• Materials: Cast Iron, Ductile Iron, Carbon Steel 1.0619+N, Stainless Steel 316L

• Connection: Flanged

• Suitable Media: Cooling Water, Brine, Hot Water, Steam and Gas

Severe Service ANSI Control Valve

Severe Service ANSI Control Valve

CVC-900A

• Size Range: 1″ – 8″ (DN 25 – DN 200)

• Pressure Rating: PN 40 / Class 300 (40 bar / 580 PSI)

• Temperature Range: –29°C to +427°C (–20°F to 801°F)

• Material: SA216 WCB Carbon Steel Casting

• Connection: Flanged or Butt Weld End

• Suitable Media: Steam, Condensate and Gases with Liquid Components

General-Purpose Globe Control Valve

General-Purpose Globe Control Valve

CVC-100

• Size Range: 1/2″ – 10″ (DN 15 – DN 250)

• Pressure Rating: PN 16 / 25 (Class 150 / 300)

• Temperature Range: –10°C to +350°C (14°F to 662°F), depending on material

• Materials: Cast Iron (EN-JL1040), Ductile Iron (EN-JS1049)

• Connection: Flanged

• Suitable Media: Refrigerants, Water Systems, Thermal Oil, Steam, Gases, Alkalis and Acids
